RS3621RPxs | RackStation RS3621RPxs
- Processor: Intel Xeon D-1531 6-core (12-thread) 2.2 GHz (Turbo up to 2.7 GHz)
- Memory: 8 GB DDR4 ECC UDIMM (expandable to 64 GB)
- Drive Bays: 12 x 3.5"/2.5" SATA HDD/SSD (hot-swappable)
- Maximum Capacity: 288 TB raw, 864 TB with expansion
- Connectivity: 4 x RJ-45 1GbE LAN, 2 x USB 3.2 Gen 1, 2 x Expansion Ports
- Dimensions: 88 x 482 x 724 mm
- Weight: 14.5 kg (without drives)
RackStation RS3621RPxs
High-Performance Data Processing
Powered by a 6-core Intel Xeon D-1531 processor, delivers up to 189,098 4K random read IOPS and 4,718 MB/s sequential read throughput, ideal for compute-intensive business applications.
Robust Data Protection
Features ECC memory, Btrfs file system with snapshot technology, and AES-256 encryption to safeguard mission-critical data against corruption and unauthorized access.
Redundant and Scalable Design
Dual 500W power supplies and hot-swappable fans ensure continuous operation, while support for up to 36 drive bays via RX1217/RX1217RP expansions meets growing storage needs.
Synology RackStation RS3621RPxs: All Features
| Drive Bays | 12 x 3.5"/2.5" SATA HDD/SSD (hot-swappable) |
|---|---|
| Connectivity | 4 x Gigabit LAN, 2 x USB 3.2 Gen 1, 2 x Expansion Ports |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD, Basic, Synology RAID F1 |
| Data Protection | AES-256 encryption, Btrfs snapshots, ECC memory |
Synology RackStation RS3621RPxs: All Specifications
| Processor | Intel Xeon D-1531 6-core (12-thread) 2.2 GHz (Turbo up to 2.7 GHz) |
|---|---|
| Memory | 8 GB DDR4 ECC UDIMM (expandable to 64 GB) |
| Drive Bays | 12 x 3.5"/2.5" SATA HDD/SSD (hot-swappable) |
| Sequential Read Performance | Up to 4,718 MB/s |
| Sequential Write Performance | Up to 2,247 MB/s |
| Random Read IOPS | Up to 189,098 (4K) |
| File System | Internal: Btrfs, EXT4; External: Btrfs, EXT4, EXT3, FAT, NTFS, HFS+, exFAT |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD, Basic, Synology RAID F1 |
| Connectivity | 4 x RJ-45 1GbE LAN, 2 x USB 3.2 Gen 1, 2 x Expansion Ports (Infiniband) |
| Protocols | SMB, AFP, NFS, FTP, WebDAV, iSCSI, Telnet, SSH, SNMP |
| Expansion | 2 x PCIe 3.0 x8 slots (for 10GbE NICs or M.2 NVMe SSD adapters) |
| Virtualization | VMware vSphere, Microsoft Hyper-V, Citrix XenServer, OpenStack |
| Dimensions (HxWxD) | 88 x 482 x 724 mm (with server handles) |
| Weight | 14.5 kg (without drives) |
| Power Consumption | 140.01 W (access), 68.76 W (HDD hibernation) |
| Noise Level | 40.7 dB(A) |
| Cooling | 4 x 80mm hot-swappable fans |
| Power Supply | Dual 500W redundant PSU, 100-240V AC, 50/60 Hz |
| System Requirements | Windows 7 or later, macOS 10.11 or later, Linux, Android, iOS |
| Software | Synology DSM, Synology Office, Chat, Calendar, Surveillance Station |
| Certifications | FCC, CE, BSMI, EAC, CCC, KC, VCCI, RCM, RoHS |
| Warranty | 5-year limited warranty |
| Package Contents | NAS unit, 2 x power cords, 2 x RJ-45 LAN cables, accessory pack, quick installation guide |
