AS6604T | LOCKERSTOR 4 AS6604T
- Processor: Intel Celeron J4125 Quad-Core 2.0 GHz (Turbo up to 2.7 GHz)
- Memory: 4 GB DDR4 SO-DIMM (expandable to 8 GB)
- Drive Bays: 4 x 3.5"/2.5" SATA 6Gb/s (hot-swappable)
- Maximum Capacity: 88 TB raw, 352 TB with expansion
- Connectivity: 2 x 2.5GbE LAN, 3 x USB 3.2 Gen 1, 1 x HDMI 2.0a
- Dimensions: 174 x 170 x 230 mm
- Weight: 2.96 kg (without drives)
AS6604T | LOCKERSTOR 4 AS6604T
High-Speed 2.5GbE Connectivity
Equipped with dual 2.5GbE ports, offering up to 5 Gbps with Link Aggregation, delivering 150% faster performance than Gigabit Ethernet for rapid file transfers and streaming.
Dual M.2 NVMe SSD Caching
Features two M.2 NVMe SSD slots for caching, significantly boosting performance for demanding applications like 4K video editing and virtualization.
4K Multimedia Experience
Supports 4K HDR playback via HDMI 2.0a with hardware-accelerated transcoding, ideal for streaming high-quality videos on Plex or ASUSTOR Portal applications.
ASUSTOR Lockerstor 4 AS6604T: All Features
| Drive Bays | 4 x 3.5"/2.5" SATA 6Gb/s (hot-swappable) |
|---|---|
| Connectivity | 2 x 2.5GbE LAN, 3 x USB 3.2 Gen 1, 1 x HDMI 2.0a |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD |
| Data Protection | AES-256 encryption, Snapshot Center, Btrfs snapshots |
| Expansion | 2 x M.2 NVMe SSD slots, supports expansion units |
ASUSTOR Lockerstor 4 AS6604T: All Specifications
| Processor | Intel Celeron J4125 Quad-Core 2.0 GHz (Turbo up to 2.7 GHz) |
|---|---|
| Memory | 4 GB DDR4 SO-DIMM (expandable to 8 GB) |
| Flash Memory | 8 GB eMMC |
| Drive Bays | 4 x 3.5"/2.5" SATA 6Gb/s (hot-swappable) |
| M.2 Slots | 2 x M.2 NVMe SSD (2280) |
| Maximum Capacity | 88 TB raw (4 x 22 TB drives), 352 TB with expansion units |
| File System | Internal: EXT4, Btrfs; External: EXT4, EXT3, FAT, NTFS, HFS+, exFAT |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD |
| Connectivity | 2 x 2.5GbE LAN, 3 x USB 3.2 Gen 1, 1 x HDMI 2.0a |
| Protocols | CIFS/SMB, AFP, NFS, FTP, WebDAV, iSCSI |
| Expansion | Supports ASUSTOR expansion units (up to 12 additional bays) |
| Virtualization | VMware, Citrix, Hyper-V, Docker support |
| Dimensions (WxHxD) | 174 x 170 x 230 mm |
| Weight | 2.96 kg (without drives) |
| Power Consumption | 26.3 W (access), 11.7 W (HDD hibernation) |
| Noise Level | 21.3 dB(A) |
| Cooling | 1 x 120mm fan |
| Power Supply | 90W external adapter, 100-240V AC, 50/60 Hz |
| System Requirements | Windows 7 or later, macOS 10.10 or later, Linux, UNIX |
| Software | ADM 3.5 or later, Snapshot Center, Cloud Backup Center, DataSync Center |
| Certifications | FCC, CE, BSMI, VCCI, C-TICK, KCC, RoHS |
| Warranty | 3-year limited warranty |
| Package Contents | NAS unit, power adapter, power cord, 2 x RJ-45 LAN cables, screws for 3.5"/2.5" drives, quick installation guide |
