DS720+ | DiskStation DS720+

Name: DS720+ | DiskStation DS720+
Brand: Synology
SKU: 11965
Availability: InStock
Rating: 4 (1 reviews)

Model: DS720+
Processor: Intel Celeron J4125 Quad-Core 2.0 GHz (up to 2.7 GHz)
Memory: 2GB DDR4 (expandable to 6GB)
Storage: 2 x 3.5"/2.5" SATA bays, 2 x M.2 2280 NVMe
Network: 2 x 1GbE RJ45
Dimensions: 166 x 106 x 223 mm
Weight: 1.51 kg (diskless)

Description
Reviews (1)

DiskStation DS720+

High-Performance Storage

The Synology DiskStation DS720+ is a compact 2-bay NAS powered by an Intel Celeron J4125 Quad-Core 2.0 GHz (up to 2.7 GHz) processor and 2GB DDR4 RAM (expandable to 6GB). It delivers sequential read/write speeds of up to 225.99 MB/s and 195.42 MB/s, respectively, with two M.2 2280 NVMe SSD slots for caching to boost I/O performance by up to 20x.

Scalable and Versatile

With support for up to 7 drives via the Synology DX517 expansion unit, the DS720+ scales up to 108TB (32TB internal). It supports RAID 0, 1, Basic, Hybrid, and JBOD, with Btrfs file system for advanced data protection, snapshots, and file self-healing. It’s ideal for home or small business data management and multimedia streaming.

Comprehensive Software Ecosystem

Running Synology DiskStation Manager (DSM), the DS720+ offers Synology Drive for cross-platform file syncing, Hyper Backup for multi-version backups, Snapshot Replication for data protection, and Surveillance Station with 2 free camera licenses. It supports Plex, DLNA, and mobile apps for remote access and collaboration.

Synology DiskStation DS720+: All Features

Processor	Intel Celeron J4125 Quad-Core 2.0 GHz (up to 2.7 GHz)
Memory	2GB DDR4 (expandable to 6GB)
Storage	2 x 3.5"/2.5" SATA bays, 2 x M.2 2280 NVMe slots
Ports	2 x USB 3.0 Type-A, 1 x eSATA
Performance	Up to 225.99 MB/s read, 195.42 MB/s write
Software	DSM, Synology Drive, Hyper Backup, Snapshot Replication, Surveillance Station
Security	AES 256-bit encryption, 2-factor authentication, Btrfs file self-healing
Compatibility	Windows 7+, macOS 10.12+, Linux, iOS, Android

Synology DiskStation DS720+: All Specifications

Model	DS720+
Processor	Intel Celeron J4125 Quad-Core 2.0 GHz (up to 2.7 GHz), 4MB cache
Memory	2GB DDR4 (expandable to 6GB)
Drive Bays	2 x 3.5"/2.5" SATA III, 2 x M.2 2280 NVMe (cache only)
Max Internal Capacity	32TB (2 x 16TB drives, varies by RAID)
Max Capacity with Expansion	108TB (7 bays with DX517)
Ports	2 x USB 3.0 Type-A, 1 x eSATA
RAID Support	RAID 0, 1, Basic, Synology Hybrid RAID, JBOD
File System	Internal: Btrfs, EXT4; External: Btrfs, EXT4, EXT3, FAT32, NTFS, HFS+, exFAT
Performance	225.99 MB/s read, 195.42 MB/s write
Encryption	AES 256-bit hardware encryption
Operating System	Synology DiskStation Manager (DSM) 7.1
Surveillance	Up to 40 IP cameras (2 free licenses included)
Power Supply	65W external adapter, 100-240V AC, 50/60 Hz
Power Consumption	28.37W (access), 10.1W (HDD hibernation)
Cooling	1 x 92mm fan
Operating Temperature	0°C to 40°C
Non-Operating Temperature	-20°C to 60°C
Noise Level	18.4 dB(A)
Dimensions (HxWxD)	166 x 106 x 223 mm
Weight	1.51 kg (diskless)
System Compatibility	Windows 7+, macOS 10.12+, Linux, iOS, Android
Certifications	FCC, CE, BSMI, VCCI, RCM, EAC, CCC, KC
Warranty	3-year limited, optional 2-year extension
Package Contents	NAS, power adapter, power cord, 2 x RJ45 cables, quick installation guide
