RS822+_RS822RP+ | RackStation RS822+_RS822RP+

Name: RS822+_RS822RP+ | RackStation RS822+_RS822RP+
Brand: Synology
SKU: 11972
Availability: InStock
Rating: 4 (1 reviews)

Model: Synology RackStation RS822+/RS822RP+
CPU: AMD Ryzen V1500B quad-core
Memory: 2GB DDR4 ECC SO-DIMM (up to 32GB)
Storage: 4x 3.5"/2.5" SATA bays
Ports: 4x 1GbE, 2x USB 3.2 Gen 1, 1x eSATA
Dimensions: RS822+: 480 x 492.6 x 44 mm; RS822RP+: 480 x 518.6 x 44 mm
Weight: RS822+: 6.4 kg; RS822RP+: 6.5 kg (without drives)

Description
Reviews (1)

RS822+_RS822RP+ | RackStation RS822+_RS822RP+

Performance and Processing

Powered by an AMD Ryzen V1500B quad-core processor (2.2 GHz), the RS822+/RS822RP+ delivers up to 2,103 MB/s sequential read and 1,074 MB/s sequential write, with over 100,000 4K random read IOPS. It includes 2GB DDR4 ECC RAM (expandable to 32GB). Users praise its efficiency for file sharing and virtualization but note fan noise (~40 dB under load) and modest base memory. Ideal for SMB file servers and backups.

Storage and Scalability

Features 4x 3.5"/2.5" SATA drive bays (drives sold separately), supporting RAID 0, 1, 5, 6, 10, JBOD, and Synology Hybrid RAID. Expandable to 8 bays with an RX418 unit. Supports NVMe/SATA SSD cache for up to 16x IOPS boost. Btrfs ensures data integrity. Users value scalability but note drive costs. Perfect for compact storage solutions.

Connectivity and Features

Includes 4x 1GbE, 2x USB 3.2 Gen 1, 1x eSATA, and 1x PCIe 3.0 x8 slot (x4 link) for 10GbE/25GbE cards. Supports Link Aggregation, failover, and Synology High Availability (SHA) clustering. Certified for VMware, Hyper-V, and Citrix. Features AES-NI encryption and DSM OS. The RS822RP+ has dual 150W PSUs. Users note reliable connectivity but report fan noise. Ideal for branch offices.

Synology RackStation RS822+/RS822RP+: All Features

CPU	AMD Ryzen V1500B quad-core (2.2 GHz)
Memory	2GB DDR4 ECC SO-DIMM (expandable to 32GB)
Storage	4x 3.5"/2.5" SATA bays, expandable to 8 with RX418
RAID	0, 1, 5, 6, 10, JBOD, Synology Hybrid RAID
Connectivity	4x 1GbE, 2x USB 3.2 Gen 1, 1x eSATA, 1x PCIe 3.0 x8
Features	Btrfs, AES-NI, DSM OS, SHA, virtualization support
Power	RS822+: 150W PSU; RS822RP+: Dual 150W redundant PSUs
Warranty	3 years (extendable to 5 years)

Synology RackStation RS822+/RS822RP+: All Specifications

CPU	AMD Ryzen V1500B quad-core (2.2 GHz, Zen architecture)
Memory	2GB DDR4 ECC SO-DIMM (2x slots, expandable to 32GB)
Storage	4x 3.5"/2.5" SATA HDD/SSD bays (drives sold separately)
Expansion	1x RX418 unit (up to 8 drives)
RAID Support	RAID 0, 1, 5, 6, 10, JBOD, Synology Hybrid RAID
Performance	2,103 MB/s seq. read, 1,074 MB/s seq. write, 100K 4K random read IOPS
File System	Btrfs, ext4
Ports	4x 1GbE RJ45, 2x USB 3.2 Gen 1, 1x eSATA
Expansion Slots	1x PCIe 3.0 x8 (x4 link) for 10GbE/25GbE cards
Virtualization	VMware vSphere, Microsoft Hyper-V, Citrix XenServer, OpenStack, Kubernetes CSI
Max Users	1,800 accounts, 1,000 concurrent connections
Max Files	5,000,000 (Synology Drive)
Power Supply	RS822+: 150W; RS822RP+: Dual 150W redundant (100–240V AC, 50/60 Hz)
Power Consumption	RS822+: 182.32W (access), 79.44W (HDD hibernation); RS822RP+: 184.42W (access), 79.62W (HDD hibernation)
Cooling	3x 40mm fans
Noise Level	RS822+: ~38.8 dB(A); RS822RP+: ~38.8 dB(A)
Dimensions	RS822+: 480 x 492.6 x 44 mm; RS822RP+: 480 x 518.6 x 44 mm
Weight	RS822+: 6.4 kg; RS822RP+: 6.5 kg (without drives)
Certifications	ECC, CE, EAC, Energy Star
Warranty	3 years (extendable to 5 years)
Software	Synology DiskStation Manager (DSM)
Accessories	RKS-02 rail kit (sold separately), Synology SATA drives, 10GbE/25GbE cards
Package Contents	NAS, accessory pack, 1x (RS822+) or 2x (RS822RP+) power cords, quick start guide
