AS5304T | NIMBUSTOR 4 AS5304T
- Model: AS5304T
- Processor: Intel Celeron J4105 Quad-Core 1.5 GHz (burst up to 2.5 GHz)
- Memory: 4GB DDR4 SO-DIMM (expandable to 8GB)
- Storage: 4 x 3.5"/2.5" SATA III bays
- Network: 2 x 2.5GbE
- Dimensions: 170 x 174 x 230 mm
- Weight: 2.2 kg (diskless)
NIMBUSTOR 4 AS5304T
High-Speed Performance for Content Creators
The ASUSTOR Nimbustor 4 (AS5304T) is a 4-bay NAS powered by an Intel Celeron J4105 Quad-Core 1.5 GHz processor (burst up to 2.5 GHz) with 4GB DDR4 RAM, expandable to 8GB. It delivers sequential read/write speeds up to 98/96 MB/s, ideal for live streamers and content creators. Dual 2.5GbE ports with Link Aggregation support up to 5 Gbps, enhancing network performance for 4K HDR streaming and large file transfers.
Multimedia and Storage Versatility
Featuring four 3.5"/2.5" SATA III hot-swappable bays, the AS5304T supports up to 72TB (4x18TB) internally and 216TB with three AS6004U expansion units. It includes an HDMI 2.0a port with 10-bit 4K and VP9 decoding for direct media playback. With RAID 0, 1, 5, 6, 10, JBOD, and Btrfs snapshots (up to 256), it ensures flexible storage and data protection.
Advanced Software and Connectivity
Running ADM 3.4 or later, the AS5304T offers Takeasy for YouTube/Twitch video archiving, iSCSI for game storage, and over 200 apps via App Central, including Plex and surveillance tools. Features like EZconnect.to, EZ Sync, and cloud backups (Amazon S3, Dropbox) ensure seamless access. With AES-NI encryption and a 3-year warranty, it’s secure and reliable for 24/7 operation.
ASUSTOR Nimbustor 4 AS5304T: All Features
| Processor | Intel Celeron J4105 Quad-Core 1.5 GHz (burst up to 2.5 GHz) |
|---|---|
| Memory | 4GB DDR4 SO-DIMM (expandable to 8GB) |
| Storage | 4 x 3.5"/2.5" SATA III bays, hot-swappable |
| Network | 2 x 2.5GbE (supports Link Aggregation, up to 5 Gbps) |
| Ports | 3 x USB 3.2 Gen 1 Type-A, 1 x HDMI 2.0a |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD, Single |
| Software | ADM 3.4+, Takeasy, EZconnect.to, EZ Sync, Snapshot Center, Plex |
| Security | AES-NI encryption, Btrfs snapshots (256), ADM Defender, Avast Antivirus |
| Compatibility | Windows XP+, macOS 10.6+, Linux, UNIX, FreeBSD |
ASUSTOR Nimbustor 4 AS5304T: All Specifications
| Model | AS5304T |
|---|---|
| Processor | Intel Celeron J4105 Quad-Core 1.5 GHz (burst up to 2.5 GHz), 4MB cache |
| Memory | 4GB DDR4-2400 SO-DIMM (expandable to 8GB, 2 slots) |
| Drive Bays | 4 x 3.5"/2.5" SATA III, hot-swappable |
| Max Capacity | 72TB (4 x 18TB drives, varies by RAID); 216TB with three AS6004U units |
| RAID Support | RAID 0, 1, 5, 6, 10, JBOD, Single |
| File System | Internal: Btrfs, EXT4; External: EXT4, EXT3, FAT32, NTFS, HFS+, exFAT |
| Network | 2 x 2.5GbE RJ45 (supports Link Aggregation, Wake on LAN) |
| Ports | 3 x USB 3.2 Gen 1 Type-A (5 Gbps), 1 x HDMI 2.0a (4K HDR) |
| Performance | Up to 98 MB/s read, 96 MB/s write (RAID 5, tested with 4.9GB folder) |
| Encryption | AES-NI 256-bit for folders and MyArchive |
| Operating System | ADM 3.4 or later |
| Power Supply | External 90W, 100-240V AC, 50/60 Hz |
| Power Consumption | ~27W (operation), ~12.6W (disk hibernation) |
| Cooling | 1 x 120mm fan |
| Operating Temperature | 0°C to 40°C |
| Non-Operating Temperature | -20°C to 70°C |
| Noise Level | ~18.6 dB(A) (HDD idle) |
| Dimensions (HxWxD) | 170 x 174 x 230 mm |
| Weight | 2.2 kg (diskless) |
| System Compatibility | Windows XP+, macOS 10.6+, Linux, UNIX, FreeBSD |
| Certifications | FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS, CCC |
| Warranty | 3-year limited |
| Package Contents | NAS, AC adapter, power cord, 2 x RJ45 cables, HDD screws, quick start guide |
