EB-L1100U | Epson EB-L1100U Laser WUXGA Projector
- Model: EB-L1100U (V11H735040/V11H735020)
- Projection System: 3LCD, laser phosphor, 0.75" D10 panel
- Brightness: 6,000 lumens (color and white)
- Resolution: WUXGA (1920x1200) with 4K Enhancement
- Connectivity: HDBaseT, HDMI, DVI-D, VGA, 5-BNC, RS-232C, Ethernet, optional wireless
- Dimensions: 520 x 484 x 189 mm
- Weight: 20 kg
Epson EB-L1100U Laser WUXGA Projector
High-Brightness Laser Projection with 4K Enhancement
The Epson EB-L1100U is a large-venue 3LCD projector with a laser light source, delivering 6,000 lumens of color and white brightness. Its native WUXGA (1920x1200) resolution with 4K Enhancement Technology (pixel-shifting to 4.6 million pixels) produces sharp, vibrant images up to 500". With a 2,500,000:1 dynamic contrast ratio, it ensures deep blacks and vivid colors, ideal for auditoriums, conference halls, and events staging. Users praise its brightness but note it requires a controlled lighting environment for optimal performance.
Versatile Lens Options and Installation Flexibility
The EB-L1100U supports nine optional interchangeable lenses (standard lens ELPLM08 included) with a throw ratio of 1.45–2.32:1 for the standard lens, enabling projections from 50" to 500". Motorized lens shift (±67% vertical, ±30% horizontal), zoom, and focus, plus lens memory for up to 10 presets, offer precise image alignment. Features like edge blending, geometric correction, and 360-degree installation suit complex setups. Users appreciate the flexibility but note high lens costs.
Advanced Connectivity and Low Maintenance
Equipped with HDBaseT, HDMI, DVI-D, VGA, 5-BNC, and optional wireless LAN, the EB-L1100U integrates seamlessly with AV systems via Crestron, AMX, and Extron control. The laser light source provides up to 20,000 hours of virtually maintenance-free operation, with no lamp replacements needed. Features like DICOM SIM, edge blending, and frame interpolation enhance professional applications. Users value reliability but report the need for professional servicing for laser issues.
Epson EB-L1100U Laser WUXGA 3LCD Projector: All Features
| Projection Technology | 3LCD, high-aperture 3-chip, laser phosphor |
|---|---|
| Brightness | 6,000 lumens (color and white), 4,200 lumens (ECO) |
| Resolution | WUXGA (1920x1200) with 4K Enhancement (4.6 million pixels) |
| Contrast Ratio | 2,500,000:1 (dynamic, AbsoluteBlack™) |
| Picture Modes | Cinema, Dynamic, Presentation, sRGB, DICOM SIM, Multi Projection |
| Light Source Life | 20,000 hours (Normal), up to 30,000 hours (Extended) |
| Interactivity | Edge blending, frame interpolation, geometric correction, lens memory, 3D-ready, DICOM SIM |
| Warranty | 3 years or 20,000 hours (whichever comes first, varies by region) |
Epson EB-L1100U Laser WUXGA 3LCD Projector: All Specifications
| Projection System | High-aperture Epson 3-chip 3LCD, laser phosphor |
|---|---|
| Brightness | 6,000 lumens (color and white), 4,200 lumens (ECO) |
| Resolution | WUXGA (1920x1200) with 4K Enhancement (4.6 million pixels) |
| Supported Resolution | VGA (640x480) to 4K UHD (4096x2160, resized) |
| Contrast Ratio | 2,500,000:1 (dynamic, AbsoluteBlack™) |
| Color Processing | 10-bit, up to 1.07 billion colors |
| Light Source | Laser diode (non-replaceable) |
| Light Source Life | 20,000 hours (Normal), 30,000 hours (Extended) |
| Throw Ratio | 1.45–2.32:1 (standard lens ELPLM08) |
| Zoom Ratio | 1–1.6x (powered, standard lens) |
| Lens | Motorized, F=1.8–2.3, f=24–38.2 mm (standard lens) |
| Lens Shift | Motorized: Vertical ±67%, Horizontal ±30% |
| Keystone Correction | Vertical: ±45°, Horizontal: ±30° |
| Audio | 10W mono speaker |
| Noise Level | 34 dB (Normal), 27 dB (ECO) |
| Power Consumption | 510W (Normal), 393W (ECO), 2W (Standby) |
| Operating Temperature | 0°C to 45°C |
| Dimensions (WxDxH) | 520 x 484 x 189 mm (excluding feet/lens) |
| Weight | 20 kg (with standard lens) |
| Interface | HDBaseT, HDMI, DVI-D, VGA in/out, 5-BNC, RS-232C, Ethernet, USB Type-B (service), optional wireless LAN |
| System Compatibility | Crestron, AMX, Extron, EasyMP, Windows, macOS, iOS, Android |
| Security | Kensington lock, password protection, customizable logo |
| Certifications | CE, FCC, RoHS, SmartWay |
| Warranty | 3 years or 20,000 hours (whichever comes first, varies by region) |
| Package Contents | Projector, ELPLM08 lens, power cable, remote control with batteries, cable cover, quick start guide |
