EB-695WI | EPSON EB-695WI WXGA 3,500 LUMENS PROJECTOR
- Model: EB-695Wi (V11H740041/V11H740553)
- Projection System: 3LCD, 0.59-inch panel
- Brightness: 3500 lumens (color and white)
- Resolution: WXGA (1280x800)
- Connectivity: 3x HDMI (1x MHL), 2x VGA, composite, USB Type A/B, Ethernet, optional Wi-Fi
- Dimensions: 367 x 400 x 149 mm
- Weight: 5.8 kg
EPSON EB-695WI WXGA 3,500 LUMENS PROJECTOR
Interactive Ultra Short Throw Projection
The Epson EB-695Wi is a WXGA (1280x800) ultra short throw (UST) interactive projector with 3LCD technology, delivering 3500 lumens of color and white brightness and a 14,000:1 contrast ratio for vibrant, sharp images in well-lit classrooms or meeting rooms. Its 16:10 aspect ratio supports up to 100" displays, projecting a 100" image from just 11" away (0.28–0.37:1 throw ratio), minimizing shadows and glare. Finger-touch and dual-pen interactivity (up to six users) enable seamless annotations, ideal for collaborative learning. Users praise its brightness and interactivity but note WXGA’s limitations for high-definition content.
Advanced Connectivity and Collaboration
The EB-695Wi features 3x HDMI (1x MHL), 2x VGA, VGA out, composite, USB Type A/B, Ethernet, RS-232C, and optional Wi-Fi (ELPAP10 adapter) for wireless projection via the iProjection app. Split-screen displays two sources simultaneously, and Moderator software supports up to 50 devices, with thumbnail previews from four (Chromebooks, iOS, Android, PCs). DuoLink enables two projectors for a seamless interactive surface. Users appreciate the versatile connectivity but report fan noise (35 dB in Normal mode) and occasional Wi-Fi setup issues in secure networks.
Reliable Design and Easy Setup
The EB-695Wi’s 250W UHE lamp lasts up to 10,000 hours in ECO mode (2900 lumens), reducing maintenance costs with auto-brightness adjustment for energy efficiency. Its compact design (367 x 400 x 149 mm, 5.8 kg) includes a wall mount bracket for easy UST setup. Keystone correction (±3° vertical/horizontal) ensures precise alignment. Users value the low maintenance and long lamp life but caution about lamp replacement costs (~$149) and the need for dust-free environments to prevent filter clogging.
Epson EB-695Wi WXGA Ultra Short-Throw Interactive Projector: All Features
| Projection Technology | 3LCD, 3-chip technology |
|---|---|
| Brightness | 3500 lumens (color and white), 2900 lumens (ECO) |
| Resolution | WXGA (1280x800), 16:10 aspect ratio |
| Contrast Ratio | 14,000:1 |
| Connectivity | 3x HDMI (1x MHL), 2x VGA, VGA out, composite, USB Type A/B, 3x stereo mini jack audio in, stereo mini jack audio out, microphone input, Ethernet, RS-232C, optional Wi-Fi (ELPAP10) |
| Software | Epson iProjection, EasyMP Multi PC Projection, EasyMP Network Projection, Moderator software, Easy Interactive Tools |
| Lamp Life | 5000 hours (Normal), 10,000 hours (ECO) |
| Compatibility | VGA (640x480) to WXGA (1280x800), iOS, Android, Chromebook, Windows 7+, macOS 10.7+, Linux, Ubuntu |
| Warranty | 3-year projector, 1-year or 1000 hours (lamp), optional CoverPlus extensions |
Epson EB-695Wi WXGA Ultra Short-Throw Interactive Projector: All Specifications
| Projection System | 3LCD, Poly-silicon TFT Active Matrix, 0.59-inch panel |
|---|---|
| Brightness | 3500 lumens (color and white), 2900 lumens (ECO) |
| Resolution | WXGA (1280x800), 16:10 aspect ratio |
| Supported Resolution | VGA (640x480) to WXGA (1280x800) |
| Contrast Ratio | 14,000:1 |
| Light Source | 250W UHE lamp |
| Lamp Life | 5000 hours (Normal), 10,000 hours (ECO) |
| Throw Ratio | 0.28–0.37:1 |
| Zoom Ratio | 1.35x (digital) |
| Lens | F=1.6, f=3.7 mm |
| Screen Size | 60"–100" (0.4–0.8 m) |
| Projection Distance | 0.47 m (80" screen) |
| Keystone Correction | Vertical: ±3°, Horizontal: ±3° |
| Connectivity | 3x HDMI (1x MHL), 2x VGA, VGA out, composite, USB Type A/B, 3x stereo mini jack audio in, stereo mini jack audio out, microphone input, Ethernet, RS-232C, optional Wi-Fi |
| Audio | 16W mono speaker, microphone input |
| Noise Level | 35 dB (Normal), 30 dB (ECO), 29 dB (ECO2) |
| Power Consumption | 354W (Normal), 309W (ECO), 0.5W (Standby) |
| Operating Temperature | 5°C to 35°C |
| Non-Operating Temperature | -10°C to 60°C |
| Dimensions (WxDxH) | 367 x 400 x 149 mm |
| Weight | 5.8 kg |
| System Compatibility | Windows 7+, macOS 10.7+, iOS, Android, Chromebook, Linux, Ubuntu |
| Security | Kensington lock, control panel lock, password protection, security cable hole |
| Certifications | CE, FCC, RoHS |
| Warranty | 3-year projector, 1-year or 1000 hours (lamp), optional CoverPlus extensions |
| Package Contents | Projector, power cable, HDMI cable, remote control with batteries, wall mount bracket, interactive pens (2x), pen tray, USB cable, software CD, user manual CD, quick start guide, warranty card |
